HLS to ASI IP Multiplexer Converter HLS to UDP IP TS Processor

$0.00

Overview DMB-9160A HLS to ASI IP Multiplexer/Converter is a high-performance, cost-effective processing device designed to solve digital TV signal sources in business locations. The device supports a maximum of three Gigabit network ports ( 2 input and 1 output). DATA1 supports RTMP/HTTP/RTSP/HLS/SRT input, DATA3 supports UDP/RTP input, and DATA2...

Quantity :

Brand : DIGICAST

Product Type : TS Multiplexer

Availability : 1000 In Stock

Overview

DMB-9160A HLS to ASI IP Multiplexer/Converter is a high-performance, cost-effective processing device designed to solve digital TV signal sources in business locations. The device supports a maximum of three Gigabit network ports ( 2 input and 1 output). DATA1 supports RTMP/HTTP/RTSP/HLS/SRT input, DATA3 supports UDP/RTP input, and DATA2 supports UDP/RTP output (4 MPTS/ 512 SPTS). Supports 2 ASI input and 4 ASI output. The equipment adopts 1U size, compact structure, high performance, low cost, high integration, good stability and so on. A single device integrates a complete set of front-end system functions, which is very suitable for all kinds of new generation digital TV broadcasting systems.

Features

* Includes 3xGigabit Ethernet DATA Ports for IP input, each data port support 128*IP(SPTS/MPTS) UDP, RTP & Unicast / Multicast

* Receive up to hundreds of ip streams, re-multiplex them as wanted,and output up 32 QAM or 16 DVB-T/ATSC/ISDB-T multi-channel RF
Frequencies with the ability to distribute hundreds of SD HD programs over Coax/terrestrial transmission
* Output:16*RFDVB-T/ATSC/ISDB-T/DTMB or 32 DVB-C for option, IP(8*MPTS/SPTS) from data1 output
* 32 or 16 Non-Adjacentfrequency out for fully use the frequency point sources
* Front panel: L1/L2/L3/H1/H2/H3 indicator light for 6*ASI input
* Web management for easy online access and management, upgrade
* Up to 180 PIDs per channel with PID remapping
* Superior Shoulders and Excellent modulation, quality MER
* Low power consumption, high reliability with MTBF(Mean Time Between Failure) ≥50000 Hours
Application & Diagram

Input	2 Gigabit IP inputs (DATA1:RTMP/HTTP/RTSP/HLS/SRT input; DATA3: UDP/RTP input)
	2 ASI input
Output	1 Gigabit output,DATA2: 4 MPTS/ 512 SPTS,UDP/RTP output
	4 ASI output
System	Web/NMS
	Chinese/English
General	Dimensions	482mm×300mm×42mm
	Weight	4kg
	Temperature	0~45℃(Operation)；-20~80℃(Storage)
	Voltage range	AC100~240V，50/60Hz
	Power consumption	<30W
