Overview

DMB-9312 MPEG-2 24-Channel SD Encoder is a broadcast level encoding platform that adopts advanced compression technology with features of ultra-low bit rate and low latency. It can provide high quality images even at low bit rate. DMB-9312 is integrated with 24 channels. Provided with an external 2*ASI input, it can be multiplexed with the local multi-programs to eliminate the needs of multiplexers, and also cascading with several encoders, to simplify the network architecture for high reliability solutions. The device supports output interfaces of ASI and IP(TSoIP) out, while the TS over IP out provides 1*MPTS or 24*SPTS over IP change by software. DMB-9312 is coupled with user-friendly NMS, to be easily upgraded via software to add new functions or improve features and enhance performance. It is the preferred device for DTV service providers and customers for its unrivaled performance, flexibility, advanced compression and high affordability per channel.

Features

• Video compression: MPEG-2  4:2:0 MP@ML
• Industry leading compression technology for MPEG-2
• Audio compression: MPEG-1 Layer2, HE-AAC and LC-AAC(optional)
• Providing ASI and IP(UDP/IP) output
• Ultra-low bit rate:1 ~ 15Mbps
• Built in PCR capability
• Dynamic GOP automatic management
• Multiplexing with external ASI in
• Providing PSI/SI compilation and NIT, LCN insertion
• PAL/NTSC modes available
• Controlled by keyboard on front-panel, LCD display
• Managed by web browser via Ethernet interface
• Upgraded via Ethernet interface
