16/24 channels Encoder

DMB-9310 Enhanced MPEG-2/H.264 SD Multi-channels Encoder features high quality video and low latency for MPEG2, MPEG4 AVC/H.264,and adopts advanced compression technology to achieve the premium viewing experience even in low bit rate. It iintegrated with 16/24 channels CVBS option, RCA interface.The device supports output interfaces of ASI (option) and IP(TSoIP)...
-
+
$2,680.00

MPEG-2 / H.264 SD Encoder

2 In Stock

DMB-9310 Enhanced MPEG-2/H.264 SD Multi-channels Encoder features high quality video and low latency for MPEG2, MPEG4 AVC/H.264,and adopts advanced compression technology to achieve the premium viewing experience even in low bit rate. It iintegrated with 16/24 channels CVBS option, RCA interface.
The device supports output interfaces of ASI (option) and IP(TSoIP) out, while the TS over IP out provides 1*MPTS or 16/24*SPTS over IP change by software. DMB-9310 Enhanced MPEG2, MPEG4 AVC/H.264 Multi-Channel Encoder’s features are proven to be of excellent performance and high reliability hardware platform designs, providing safety and stability for Cable, Satellite, IPTV or Terrestrial applications.



FEATURES

  • Video compression options: MPEG-2, MPEG4/H.264 SD
  • Video input: 16/24×CVBS
  • PAL/NTSC modes available
  • Support Logo, QR code, Caption insertion
  • Audio compression options: MPEG1Layer 2, LC-AAC, HE-AAC Audio encoding
  • ProvidingPID Remapping, PCR accurate adjusting and PSI/SI editing and inserting
  • IP (16/24*SPTS or1 MPTS) output through data port(data1 or data 2 option)
  • Null PKT Filter” function
  • Providing 1*ASI output (optional) as copy of MPTS
  • Managed by web browser via Ethernet interface
  • Upgraded via Ethernet interface



SPECIFICATIONS

Transport Stream Input Interfaces

Video Encodering

Video compression: MPEG-2, MPEG4/H.264 SD
Video inputs: 16/24 CVBS inputs, RCA interface
Analog video input mode: PAL, NTSC
GOP Structure: IPPP, IBPBP, IBBPB, IBBBP
Advanced Pretreatment: De-interlacing, noise reduction
Rate Control: CBR/VBR
Input/Output Resolution:
Input:720*576@50i (PAL)
Output:720*576/352*288/320*240/320*180/176*144/160*120/160*90@50Hz
Input: 720*480@60i (NTSC)
Output: 720*480/352*288/320*240/320*180/176*144/160*120/160*90@60Hz
Bit-rate: 0.5~5Mbps
Video pre-processing: De-interlacing, Noise reduction

 Audio Encodering

Audio compression: MPEG-1 Layer 2, LC-AAC, HE-AAC
Sampling rate: 48KHz
Resolution: 32-bit
Audio bit-rate: 48Kb/s~384Kb/s (each channel)

IP Stream output

1 ASI out as copy of MPTS (Option)
IP (MPTS/SPTS) output over UDP/RTP/RTSP
Connector: RJ45,1000Ml 1 ASI out as copy of MPTS (Option)
IP (MPTS/SPTS) output over UDP/RTP/RTSP
Connector: RJ45,1000M

Multiplexing

PID remapping (automatically or manually)
Accurate PCR adjusting
Generate PSI/SI table automatically

System function

Network management (WEB)
English language
Ethernet software upgrade



GENERAL OPTIONS

Physical and Power

Power requirements:AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz
Power Consumption: 20W
Operating temperature: 0~45℃
Dimensions: 482mm(W)*410mm(D)*44mm(H)
Weight: 8 KG ((including accessories)

DIAGRAM
