Multi-Channel Professional IRD

DMB-9060B Multi-Channel Professional IRD is a high-density and flexible device, integrating broadcast level receiver, demodulation, decryption, de-mux, re-mux and decoding function. It supports ASI,IP and various of Tuners input which can be selected respectively from DVB-S/S2,DVB-T/T2, DTMB/ATSC-T/ISDB-T and DVB-C for option with 2/4*Tuner independent input. And also capable of receiving...
-
+
$1,230.00

Professional IRD

2 In Stock

DMB-9060B Multi-Channel Professional IRD is a high-density and flexible device, integrating broadcast level receiver, demodulation, decryption, de-mux, re-mux and decoding function. It supports ASI,IP and various of Tuners input which can be selected respectively from DVB-S/S2,DVB-T/T2, DTMB/ATSC-T/ISDB-T and DVB-C for option with 2/4*Tuner independent input. And also capable of receiving lots of programs from different frequencies. Meanwhile, it delivers reliable video quality program source with advanced video decoding (HD/SD H.264 & MPEG-2) technology, outputs: TS*2(backup) +IP (MPTS/SPTS) and monitoring: 2/4*CVBS(Independent),2/4*SDI(each channel SDI can embedded 2 channel audio). With its 4*DVB common interface slots and BISS decryption, capable of working with most of well-known CAS in the market to decrypt multiple TV pay services. With the compact design and the excellent decoding ability,DMB-9060B is becoming very popular among distribution system, IPTV applications and digital TV head-end system for DTV operators, broadcast service providers and IPTV integrators etc.



Features

  • Support Max. 4*Tuners input selectable from DVB-T/T2, DVB-C, DVB-S/S2,

    DTMB/ATSC-T/ISDB-T

  •  Capable of demodulation, CI & BISS 1 or BISS E decryption and decoder

  •  Support HD/SD MPEG-2,H.264 video decoding, Close Caption, Subtitle and Teletext

  • Audio output supports MPEG1 Layer1/2, MPEG2 Layer2, AAC-LC, HE AAC V1/V2

  •  Support AVS+DRA audio decoding at the same time

  •  Support multiple programs from tuner, ASI and IP decryption via the CAM card

  •  Support 4*CVBS(independent) and 4*SDI output(each channel SDI can embedded 2 channelaudio PIDs).

  •  Support DVB Mode 11*IP out by 600Mbps. Full duplex mode, 2*in/2*

    out by each 120Mbps; Or IPTV mode 128*IP output by 400Mbps.

  •  Support volume of Digital and Analog audio adjusted independently

  •  SDI input audio 32K, 44.1K, 48K adoption supported.

  •  Signal channel SDI support double channel AC3 pass through

  •  Support auto-preserving programs

  •  Support NTSC and PAL SECAM modes available

  •  Management of support web browser via Ethernet interface

  •  Support software upgrading by Ethernet interface

  •  Double power supply design

  •  Power-off memory function



SPECIFICATIONS

TRANSPORT STREAM INPUT

DVB-S/S2 Tuner Input

Connector: 4×DVB-S/S2 Tuner, F-female 75Ω

Input Frequency Range: 950~2150MHz

RF Input Level:-65~-25dBm

Constellation: QPSK, 8PSK

Symbol rate: 2~45Mbaud

FEC encoding Rate: DVB-S QPSK: 1/2, 2/3, 3/4, 5/6, 7/8

DVB-S2 QPSK: 1/2, 2/3, 3/4, 3/5, 4/5, 5/6, 8/9, 9/10

DVB-S2 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10

Roll off: DVB-S QPSK 0.35

DVB-S2 8PSK 0.35,0.25, 0.2

Symbol rate: 2~45Mbaud

LNB Polarity Selection Voltage: 0,13V,18V selectable.

LNB Band Selection Tone: 0/22KHz selectable.

Satellite Selection Command: DiSEqC 1.0

DVB-C Tuner Input

Connector: 4×DVB-C Tuner, F-female 75Ω

Standard: J.83A(DVB-C), J.83B, J.83C

Input frequency: 51~862MHz

Input Level: 45~75dBuV

Constellation: 16/32/64/128/256QAM

Bandwidth: 6MHz,7MHz,8MHz

Input Return Loss: 7dB

Symbol Rate: 1~7MBaud(ITU J.83 Annex A)

DVB-T/T2 Tuner Input

Connector: 4×DVB-T/T2 Tuner, F-female 75Ω

Input frequency: 104~862MHz(VHF/UHF)

RF Input level:-70~-20dBm

Constellation: DVB-T: QPSK,16QAM,64QAM

DVB-T2: QPSK, 16QAM, 64QAM, 256QAM

Bandwidth: 6MHz/7MHz/8MHz

FFT : DVB-T: 2K/8K

DVB-T2: 1K, 2K, 4K, 8K, 16K, 32K

Guard interval: DVB-T: 1/4, 1/8, 1/16, 1/32

DVB-T2: 1/4, 5/32, 1/8, 5/64, 1/16, 1/32, 1/64, 1/128

FEC: DVB-T: 1/2, 2/3, 3/4, 5/6, 7/8

DVB-T2: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6

Reflection loss: 7dB (typ.)

DTMB Tuner Input

Frequency range: 46~862MHz

RF input level:-87~-29dBm

Symbol rate: 7.56Mbaud

Constellation: 4QAM, 4QAM-NR, 16QAM, 32QAM, 64QAM

Bandwidth: 6MHz/7MHz/8MHz

Connector: 4*F type, female 75Ω

ISDB-T/Tb Tuner Input

Frequency range: 153~862MHz

RF input level:-70~-25dBm

FFT: 2K, 4K, 8K

Constellation: DQPSK, QPSK, 16QAM, 64QAM

Bandwidth: 6MHz/7MHz/8MHz

Connector: 4*F type, 75Ω

ATSC Tuner Input

Frequency range: 54~864MHz

RF input level:-75~-7dBm

Constellation: 8VSB

Bandwidth: 6MHz

Connector: 4*F type, 75Ω

ASI Input

1*BNC 75Ω

Standard: DVB-ASI, EN50083-9

Input bit rate:≤ 100Mb/s

TS Over IP

Connector type: (1+1)*RJ-45,100/1000M Base-T

Max. Bitrate:

120Mb/s x 4CH for full duplex(2*IP IN & 2*IP OUT).---Full duplex Mode.

400Mb/s for 128*IP(MPTS/SPTS) output.-----IPTV Mode.

600Mb/s for 11*IP(MPTS/SPTS) output.-----DVB Mode.

Transmission Protocol: UDP/RTP Unicast, Multicast, ICMP, ARP, IGMPv2, IGMPv3

TS Processing

1*ASI input for re-mux, BNC interface

For TS from Tuner, ASI, TS/IP and the encoded programs, enable proceeding Re-mux and de-mux

After TS Re-mux and De-mux, can output by (1+1)*ASI connector

Program and PID Processing: Support Program Re-mux, PID filter and mapped functions

PSI/SI Processing: Support PSI/SI table produced, NIT and SDT editing, and LCN‘s editing and re-production.

Descrambling: DVB common scrambling algorithm (CSA)

CI slots: 2×PCMCIA Slots, comply with most major CAMs in market

Capable of BISS-1.BISS-E decryption

TRANSPORT STREAM OUTPUT

ASI Output

Connector: (1+1)*ASI, BNC Female, 75Ω

Standard: DVB-ASI, EN50083-9

Output bit rate: ≤100Mb/s

SDI Video Output

(2+2)/(4+4)*SD/HD SDI, BNC Female, 75Ω

Video Decoding standard: comply with MPEG-2(MP@ ML for SD, MP@HL for HD), MPEG 4/H.264 AVC Part 10 (MP@L3 for SD, HP@L4.1 for HD), AVS Benchmark grade @level 6.0,AVS-P16

Resolution & Frame Rate: 1080i×30, 1080i×29.97, 1080i×25, 720p×60, 720p×59.94, 720p×50,576i×25, 480i×29.97

SD SDI Standard: SMPTE 259M, 270 Mb/s (10bit)

HD SDI Standard: SMPTE 292M, 1.485 Gbit/s (10bit)

Video bit rate: ≤80Mb/s

Output level: 800mV p-p

Digital Audio Processing

Output Format: SDI embedded audio(2*audio decoding per SDI)

Connector: BNC, Female 75Ω

Adoption: 32KHz, 44.1KHz, 48KHz

Audio Format: MPEG1 Layer1/2, MPEG2 Layer2, AAC-LC, HE AAC V1/V2

CVBS Video Output

Connector Type: 2/4*CVBS, BNC Female 75Ω

Standard: NTSC, PAL, SECAM

Resolution & Frame Rate: 576i×25, 480i×29.97

Frequency response: SMPTE 259M, 270 Mb/s (10bit)<±1 dB, 5.5 MHz(PAL, SECAM)

4.2MHz (NTSC)

Chroma-luma delay: <±30 ns

Field Time Distortion: <2%

Output level: 1.0 Vp-p±5%

Line Time Distortion: <1%

Short Time Distortion: <2%

Differential Gain:<3%

Differential Phase:<2°

Noise-signal Ratio: >55dB(Luminance Weighted)

Analog Audio Output

Audio Decoding: 4*Stereo output (support 4 audio PID decoding or 8 channels)

Connector Type: 2xD-sub9(XLR adaptor)

Output Impedance: 600Ω (Balanced)

Output Mode: Left, Right, 2*mono, stereo

Crosstalk Among Channels: >70dB

Total Harmonic Distortion: <0.3%(Testing: 400Hz, 1KHz)

Frequency response: ±0.5dB(20Hz~18KHz)

Output Level:-30~+7dB(Adjustable, 0dBm/600Ω)

Ancillary Data Processing

Subtitle: DVB EBU

VBI: Teletext, WSS

Closed Caption: EIA608, EIA708, EIA608-to-EIA708








DIAGRAM
