Re-Modulator

DMB-2416 Multi-channel Remodulator designed with high compact for capture signals from satellite DVB-S/S2(T/T2/ATSC/ISDB-T optional) and convert to digital RF(DVB-T or DVB-C for option), moreover built-in all-in-one features of multiplexing and scrambling(only for DVB-C). It’s the professional and high cost-performance equipment tailor for Hotel/School/Hospital distribution TV. Considering for future-proof features DMB-2416...
-
+
$1,980.00

DTV Modulator Series

2 In Stock

DMB-2416 Multi-channel Remodulator designed with high compact for capture signals from satellite DVB-S/S2(T/T2/ATSC/ISDB-T optional) and convert to digital RF(DVB-T or DVB-C for option), moreover built-in all-in-one features of multiplexing and scrambling(only for DVB-C). It’s the professional and high cost-performance equipment tailor for Hotel/School/Hospital distribution TV. Considering for future-proof features DMB-2416 equipped with IP input(512*SPTS/MPTS) and IP output(1*MPTS) which could be expanded the channels to IPTV system or capture signals from IP source.

FEATURES

  • Up to 16*DVB-S2/S (T/T2/ATSC/ISDB-T optional) FTA
  • Tuner, 2*ASI and 512*IP(GE1 only) input over UDP and RTP protocol.
  • 8*DVB-T or 16*DVB-C RF Output for option.
  • Capable of scrambling only for DVB-C Modulation.
  • Up to 16 groups multiplexing, 16 groups scrambling and 16 groups QAM modulation
  • Offering adjust the PCR in precisely.
  • Easy to configure via Web-based management.



 APPLICATIONS

  • IPTV & OTT system
  • Digital Signage Project
  • Digital TV Broadcasting System
  • Hotel Distribution TV System
  • CATV Broadcasting system





SPECIFICATIONS

INPUTS
TRANSPORT STREAM INPUT
16*DVB-C (DVB-T/T2/S/S2,ATSC,ISDB-T for option) FTA Tuner
512 IP (GE1 only)input over UDP and RTP protocol
2 ASI input, BNC interface
TUNER INPUT
DVB-C
Standard: J.83A(DVB-C), J.83B, J.83C
Frequency In: 30 MHz~1000 MHz
Constellation: 16/32/64/128/256 QAM
DVB-T/T2
Frequency In: 30MHz ~999.999 MHz
Bandwidth: 6/7/8 M bandwidth
DVB-S/S2
Input Frequency: 950-2150MHz
Symbol rate: QPSK 1~45Mbauds
8PSK 1~45Mbauds
Code rate: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
Demodulation Mode: QPSK, 8PSK
ISDB-T
Input Frequency: 170~860MHz
ATSC
Input Frequency: 30MHz~1000MHz
Bandwidth: 6M

Multiplexing
Maximum PID Remapping: 128 input per channel
Function: PID remapping (automatically or manually)
Accurate PCR adjusting
Generate PSI/SI table automatically

OUTPUTS
Modulation(optional)
DVB-C Modulation
QAM Channel: 16
Standard: EN300 429/ITU-T J.83A/B
MER: ≥40db
RF frequency: 50~960MHz, 1KHz step
RF output level: -20~+10dbm(87~107 dbµV),0.1db step
Symbol Rate: 5.0Msps~7.0Msps, 1ksps stepping
Constellation: 16/32/64/128/256QAM
Constellation: 16/32/64/128/256QAM(J.83A); 64/256 QAM(J.83B)
Bandwidth: 8M(J.83A); 6M(J.83B)
DVB-T Modulation
Channel: 8*DVB-T adjacent frequencies
Modulation standard: EN300 744
Bandwidth: 6M, 7M, 8M
Constellation: QPSK, 16QAM, 64QAM
FFT mode: 2K
Guard interval: 1/4, 1/8, 1/16, 1/32
MER: ≥42dB
RF output frequency range: 50~960MHz, in 1KHz steps
RF out: 4* COFDM DVB-T out (4 carriers combined output)
RF output level: -28~-3dBm (79~104dbµV), in 0.1dB steps
IP out
1 IP (MPTS) output over UDP and RTP/RTSP (GE1 only), As mirror of one carrier
SCRAMBLING(Only for DVB-C Modulation)
Max simulscrypt CA: 4
Scramble Standard: ETR289, ETSI 101 197, ETSI 103 197
Connection: Local/remote connection
QAM Channel: 16
Standard: EN300 429/ITU-T J.83A/B
MER: ≥40db
RF frequency: 50~960MHz, 1KHz step
RF output level: -20~+10dbm(87~107 dbµV),0.1db step
Symbol Rate: 5.0Msps~7.0Msps, 1ksps stepping
Constellation: 16/32/64/128/256QAM
Constellation: 16/32/64/128/256QAM(J.83A); 64/256 QAM(J.83B)
Bandwidth: 8M(J.83A); 6M(J.83B)


GENERAL OPTIONS
Management
Connector: 1*RJ-45, 10/100 Base-T interface.
Front panel and web browser via Ethernet interface
Upgradable: Upgradable: Ethernet, software
Physical and Power
Power Supply: AC 100V±1050/60Hz; AC 220V±10%, 50/60HZ
Operational temperature: 0~45°C
Storage temperature: -20~80℃
Dimension: 482mm(W)×300(D)mm×44.5mm(H)
Weight: 4.5kg



DIAGRAM
