Tuner to RF Trans-Modulator

DMB-24E Series IP To 16*DVB-T professional Trans-modulator, with 4 independent modulating modules, each modules support 4* frequencies output, the back panel support 3 groups modulation modules, so that realize 12 frequencies RF output, and in the inner Main board, support 1 group RF output. Totally which support 16*DVB-T RF output....
-
+
$1,699.00

DTV Modulator Series

2 In Stock

DMB-24E Series IP To 16*DVB-T professional Trans-modulator, with 4 independent modulating modules, each modules support 4* frequencies output, the back panel support 3 groups modulation modules, so that realize 12 frequencies RF output, and in the inner Main board, support 1 group RF output. Totally which support 16*DVB-T RF output. Each modules of them support 4* Giga port IP input and multiple ASI in and output, and very powerful realized any programs multiplexing, then modulation output, It is professional and ideal device for Digital TV head-end.

FEATURES

  • 4 independent modules
  • Two separate ASI input for External TS Multiplexing
  • 4 separate multiplexing and Up-converter modulating adjacent carrier out, Output RF standard support DVB-T/DVB-C/ATSC/ISDB-T/DTMB option from UI, only need reboot the device after switch the output RF standard
  • IP output: Only 1 * MPTS,UDP/RTP
  • PID Remapping & Filtering
  • PSI/SI editing & inserting
  • Low cost solution for Hotel TV System
  • Support PCR correct and PCR interval adjusting
  • Superior Shoulders and Excellent modulation
  • quality MER
  • Low power consumption and high reliability with
  • MTBF(Mean Time Between Failure) ≦87600 Hours
  • Easy-to-Use System Management via Web
  • Highly compact , High-Integrate
  • Support LCN (Logical Channel Number



APPLICATIONS



SPECIFICATIONS

DVB-T MODULATIONS
FFT Mode: 2K, 8K
Bandwidth: 6M, 7M ,8M
Constellation: QPSK, 16 QAM, 64QAM
Guard Interval: 1/4, 1/8, 1/16, 1/32
MULTIPLEXING
Maximum PID Remapping: 180 input per channel
PID remapping by automatically or manually
PSI/SI: SDI/PMT/TOT/PAT/BAT/CAT/TDT/NIT Insert, Accurate PCR adjusting
Max numbers: 4 mux for RF and 1 Mux for 1*MPTS (1*MPTS channels can Separate MUX)
IP INPUTS
Support 128* IP Streaming input
ASI INPUTS
2*DVB-ASI inputs
Connector: BNC female, 75Ω
Signal Level: 200-800mVp-p
Packet Length: 188 bytes
Maximum bit-rate: per port≤100Mbps
Number of Input Ports: Dual separate ASI ports
ASI OUTPUT
DVB-ASI: 2 Separate ASI, 75Ω, BNC, 188Bytes
MPEG-2: TS over DVB-ASI (EN 50083-9)
MULTIPLEXING SPECIFICATIONS
Maximum PID Remapping 180 input per channel
PID remapping by automatically or manually
Accurate PCR adjusting
PSI/SI SDI/PMT/TOT/PAT/BAT/CAT/TDT/NIT Insert


GENERAL OPTIONS
CONTROL AND MONITORING
Configuration Interface: Web-based, NMS
Remote: Upgrade via network
Connector: RJ45, 100M/1000M Ethernet interface
PHYSICAL AND POWER
Voltage 110~220V
Consumption: 18~20W
Operating temperature: 0~50°C
Dimensions: 483mm(W)*360mm(D)*44.5mm(H)
Weight: 5KG/pc



DIAGRAM
