OVERVIEW

DMB-8900A-EC USB series ProVideo Streaming Encoder features high performance, low latency and low bit rates for IPTV/OTT systems, realized Video & Audio real-time transmission via internet, and adopts state-of-the-art compression technology of H.265/H.264/MJPEG, which realizes HDMI resolution to be up to 4K @30,USB support capture YUV camera supports up to 1080P60 frame picture, After upgrading the firmware with video function, the USB port can be connected to a U disk for video recording.MJPEG compression format supports low-latency playback on computers and mobile browsers. The PTE private protocol realizes the low-latency transmission of the LAN with only 80-200 milliseconds.With powerful video pre-compression and efficient adaptive video compression algorithm, it is able to provide clear-delicate, high quality video even at lower bit rate which can efficiently save the cost of bandwidth. DMB-8900A-EC USB Series ProVideo Streaming Encoder accepts 1*HDMI or 1* USB input, then output 4 groups TS over IP (including 1 main stream and 3 secondary streams) in H.265 format with multi-protocol, multi-resolution which can be freely adjusted according to your needs.

DMB-8900A-EC USB series provides fully functional second development package, which can be applied to education, health care, IPTV, conference, remote education, news interview, court, public security, banking, transportation and other industry application.

Features

• Video Input: 1*HDMI+ 1*USB+ 5mm in
• Video compression up to 4K@30 (HDMI input),1080P@60 (USB input)
• Dolby AC3audio compression
• Support 265High/Main/Baseline Profile and AC3, AAC, MP3, MP2 audio compression
• Bitrate mode: CBR/VBR/Strong CBR 16kbps~12Mbps
• Support streaming resolution settings
• Capable of image parameter settings
• Insertable of logo and Scroll Caption; Adjustable of audio gain;
• Video Output: Multiple output streams per input service to support Broadcast, VOD, IPTV and OTT, Mobile/ web, Set top box applications
• Support up to 4 groupsTS over IP stream out.
• Switchable of audio output mode: Left, right and Stereo
• Configurable of Multi-rate, Multi-resolution, Multi-protocol
• Providing RTMP/RTMP(S)/RTSP/HTTP TS/HTTP FLV/HLSTS/HLS MP4/MP4/SRT/UDP/RTP protocol
• SupportHDCP technology, ONVIF Network Video Protocol
• Support multiple equipment display at the same time on a computer
• Any IOS browsers(iphone, ipad, MacBook etc) are able to have streams from IPTV Streaming Encoder in Anytime, Anywhere by HLS protocol without install any software players
• Any terminal devices/decoders are able to have streams from IPTV Streaming Encoder directly by RTMP protocol with software players(such as VLC).
• System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64, LINUX
• Support Microsoft standard flow driven architecture (WDM architecture), support Microsoft WMENCODER, compatible with Windows VFW software architecture and WDM mode.
• Web-based management
• Full-duplex mode 1000M
